| Brand Name : | YONGJIELI |
| Model Number : | CDD40 |
| Certification : | CE |
| Price : | USD2470.00 - USD10300.00 |
| Payment Terms : | L/C, T/T, D/A, D/P, Western Union |
| Supply Ability : | 50 SETS PER MONTH |
| Delivery Time : | 10 WORK DAYS |
Specification:
1.High wear-resistant polyurethane wheels (load-bearing wheels, driving wheels,
balancing wheels)
2. Walking style
3.Handle with shock absorption
4.Waterproof plug-in
5.Multifunctional power meter
6.Electromagnetic brake
7.Electronic steering
8. Speed limit on bends
9.Omron induction switch
10. Dual lifting cylinders
| Model | CDD40(Walking style) |
| Load Capacity(KG) | 4000 |
| Max.Lift Height(mm) | 2500 |
| Load Center(mm) | 500 |
| Max.Load Capacity at Max.Height(kg) | 2500 |
| Tire Material | Polyurethane Solid Tire |
| Fork Dimension(mm) | 1070*120 |
| Mast Type | Two Stage Mast |
| Fork Adjustment Range(mm) | 400-800 |
| Fork Leg Inner Width(mm) | 1280 |
| Overall Lenght(mm) | 2265 |
| Overall Width(mm) | 1520 |
| Height of Closed Mast(mm) | 1750 |
Max.Height of Lifting Fork (Including Fork)(mm) | 3360 |
| Tuning Radius(mm) | 1790 |
| Min.channel of Stacking(mm) | 2650 |
| Max.Driving Speed Km/h | 4.0/5.0 |
| Climing Capacity % | 3/6 |
| Total Weight (kg) | 1250 |
| Driving Wheel(mm) | 230*75 |
|
